BIG-IP iSeries 平台

BIG-IP iSeries 设备所交付的应用程序服务具有快捷编程能力、多供应商服务编排、软件定义型硬件,以及线路速率性能等诸多特点。

来自 F5 的高度可编程、云就绪硬件选项。

BIG-IP iSeries 平台采用 TurboFlex 优化技术,从通用 CPU 中卸载专用功能,从而使其性价比达到主要竞争对手的两倍。借助 TurboFlex,您可以从不同的性能配置文件中进行选择,并在业务需求发生变化时切换至新配置文件。最出色的是,未来软件更新还会启用更多优化内容和配置文件。

Gain Agility with The Most Programmable Cloud-Ready ADC

The BIG-IP iSeries platform combines software and hardware innovations that balance the need for performance, scalability, and security. The next-generation iSeries delivers record breaking, software-defined hardware performance, quick and easy programmability and ecosystem-friendly orchestration. IT can offload SSL processing and deploy comprehensive application delivery and security services anywhere, in any architecture and deployment model. As a result, enterprises of all sizes can accelerate private clouds and secure critical data at scale while lowering TCO.

Read the datasheet ›

Unify Application Delivery

数字化转型

降低 TCO

借助支持卓越性能和敏捷性的下一代 ADC 解决方案,充分利用应用程序开发的飞速增长。

白皮书
促进性能和敏捷性的 BIG-IP iSeries 架构
阅读白皮书 ›

大规模合规

保护敏感数据

经过 FIPS 和通用标准认证的 F5 BIG-IP 平台,助您遵守监管要求并对所有环境实施最为完善的保护措施。

认证资质
遵守政府法规,维护安全 IT 环境
了解更多 ›

性能和安全性

保护重要数据

BIG-IP iSeries 平台所运用的创新技术手段能够在性能、可扩展性和安全性间做出平衡,支持 IT 卸载 SSL 处理并在任何位置部署综合性应用程序交付和安全性服务。

成功案例
服务提供商提供卓越的 5G 网络性能
查看使用案例 ›

速度与灵活性

让性价比翻倍

对比业内领先的竞争对手,借助 F5 TurboFlex 优化技术从通用 CPU 中卸载特定功能可使性价比实现翻倍。根据业务需求更改性能配置文件。

视频 | TurboFlex
让性能在关键时刻得到充分发挥
查看工作原理 ›

缩短部署时间

提供对主流私有云堆栈(包括 OpenStack、VMware 和 Cisco)的支持,进而缩短部署时间。

改善部署时间

编程工具包可灵活运用可定制的应用程序模板、JavaScript 社区和 25 万个以上的 node.js 库。

合并应用程序服务

与其他应用程序交付控制器 (ADC) 供应商相比,拥有成本削减了高达 53%。

F5 BIG-IQ CENTRALIZED MANAGEMENT

Automation and Orchestration

Manage all your BIG-IP devices from one place. BIG-IQ Centralized Management provides a central point of control for F5 physical and virtual devices. It simplifies management, helps ensure compliance, and gives you the tools you need to deliver your applications securely and effectively.

Learn more ›

THE BIG-IP ISERIES CATALOG

The F5 BIG-IP iSeries platform features programmable cloud-ready ADC appliances with unrivaled Layer 4 and Layer 7 throughput and connection rates. To support regulatory compliance, the BIG-IP iSeries of appliances has earned NIST FIPS 140-2 Level 2 and Common Criteria Evaluation Assurance Level (EAL 4+) certification. The hardware-accelerated support for ECC ciphers provides a cost-effective way to ensure privacy for any-size enterprise:


LARGE ENTERPRISES AND SERVICE PROVIDERS

BIG-IP i15000 Series / 2RU

The i15000 series delivers high-end performance for security and services in a 2 RU form factor. With 300M L4 concurrent connections, the i15x00 enables consolidation of multiple services on a single device, including TCP/IP optimization, traffic steering, firewall, DDoS, CGNAT and DNS. The i15000 series features:

  • quadruple TurboFlex FPGAs
  • 2x 14-Core Intel Xeon processors,
  • 1.6TB of available use storage space
  • 512GB DDR4 RAM
  • 4x 100G and 8x 40G fiber ports

The i15000 appliances provide the highest density of high-speed ports per rack unit available in an appliance as well as the highest L4 throughput, supporting 320/160G of L4/L7 throughput and up to 10M L7 RPS.

BIG-IP i11000 Series / 1RU

The BIG-IP i11000 series of high-performance ADC appliances include dedicated crypto-hardware to enable SSL offloading and hardware-based support for elliptical curve cryptography (ECC) ciphers. The i11800 appliances offer the highest L7 request-per-sec performance in a 1RU form factor. The i11000 series features:

  • dual TurboFlex FPGAs
  • 18-Core Intel Xeon processor
  • 256GB DDR4 RAM
  • 960GB enterprise class solid-state drive (SSD)
  • dual 80 Plus Platinum-certified, high-efficiency power supplies

The i11000 series supports up to 180M L4 concurrent connections and up to 32 vADC guests for consolidating application and security services, including L4 – L7 traffic management, DNS, DDoS protection, and web application firewalls.


MID-TO-LARGE ENTERPRISES

BIG-IP i10000 series / 1RU

The BIG-IP i10000 series of ADC appliances offer high performance and availability, featuring dedicated crypto-hardware for SSL offload and hardware-based support for elliptical curve cryptography (ECC) ciphers, and:

  • dual TurboFlex FPGAs
  • 8-Core Intel Xeon processor
  • 128GB DDR4 RAM
  • 480GB enterprise-class, solid state drive (SSD)
  • dual 80 Plus Platinum-certified, high-efficiency power supplies

The i10000 series of appliances is available as a 1RU appliance and supports up to 100M L4 concurrent connections, up to 16 vADC guests, and 160/80G of L4/L7 throughput.



BIG-IP i7000 series / 1RU

The BIG-IP i7000 series of mid-to-high performance ADC appliances features:

  • TurboFlex optimization technology
  • 6-Core Intel Xeon processor
  • 96GB DDR4 RAM
  • 480GB enterprise class solid-state drive (SSD)
  • dual power supplies

Compared to previous models, this 1 RU ADC offers twice the Layer 4/7 throughput and Layer 4 concurrent connections, 60 percent more SSL TPS, and supports 50 percent more vADC guests.

BIG-IP i5000 series

The BIG-IP i5000 series offers best-in-class performance for advanced mid-range ADC appliances and features:

  • TurboFlex optimization technology
  • 4-Core Intel Xeon CPU
  • 48GB DDR4 RAM
  • 480GB enterprise class solid-state drive (SSD)
  • eight 10GbE SFP+ ports
  • four 40GbE QSFP+ ports

Compared to previous models, the i5800 ADC provides twice the Layer 4 throughput and concurrent connections, and 67 percent more SSL TPS.


SMALL-TO-MEDIUM ENTERPRISES

BIG-IP i4000 series

The mid-range BIG-IP i4000 series of ADC appliances offer exceptional performance that meets most small-to-medium sized enterprise application and security service requirements. This i4000 series features:

  • 4-Core Intel Xeon CPU
  • 32GB DDR4 RAM
  • 500GB enterprise-class hard drive
  • eight 1GbE fiber ports
  • four 10GbE SFP+ ports

The i4800 series provides double the Layer 4 throughput, 2.8x the Layer 4 concurrent connections, and 2.2x the SSL TPS than comparable models.

BIG-IP i2000 series

The entry-level BIG-IP i2000 series of high-performance ADC appliances provides small-to-medium sized enterprises with integrated application delivery and security services. This series features:

  • 2-Core Intel Xeon CPU
  • 16GB DDR4 RAM
  • 500GB enterprise-class hard drive
  • four 1GbE fiber ports
  • two 10GbE SFP+ ports

The i2800 series provides double the Layer 4 throughput, 2.8x the Layer 4 concurrent connections, and 1.5x the Layer 7 requests-per-second than comparable models, with support for GBB bundle licensing.

了解 TurboFlex 技术如何同时为您提供速度与灵活性。

Enterprises and service providers rely on F5 BIG-IP iSeries appliances to unify application delivery and security services for both emerging and mission-critical applications.

F5 VIPRION PLATFORM

Lower Costs and Extend Infrastructure

Accelerate private clouds and secure critical data at scale—in both established and emerging application architectures—with the most flexible and powerful application delivery controller available. With the VIPRION Chassis and Blades, enterprises and service providers can add blades without disrupting apps or users to extend power without adding devices.

Learn more ›
